| ELECTRONIC LOCKS & AUDIO / VIDEO DOOR PHONES |
|
 |
|
| Brand: |
M-TEK |
| Model |
MTADP-16 |
| Product Name: |
Audio Door Phone |
| Product Warranty: |
365 Days |
|
Features |
| |
» |
Individual, household door entry system in three style 1+1, 1+2 and 1+4 |
| |
» |
1 Piece door Phone Plus 1 Piece Interphone Easywiring |
| |
» |
Dual-way Communication |
| |
» |
AutoDoor-Releasing by Interphone |
| |
» |
Stylish Design Aluminum front panet DoorPhone |
|
|
|
|
 |
|
| Brand: |
M-TEK |
| Model |
MT-11K |
| Product Name: |
Audio Door Phone |
| Product Warranty: |
365 Days |
|
Features |
| |
» |
Product Function : Talk with Door Station / Door Release |
| |
» |
Connectable product : DR-2AG, DR-2A2N, DR-2A3N, DR-2AN |
| |
» |
Connectable product : DR-2GF, DR-2G, DR-201D, DR-2K |
| |
» |
Connectable product : DR-20S, DR-201A |
| |
» |
Material : Plastic |
|
Specifications |
| |
» |
Wiring : Door – 2 wires, Door Release – 2 wires |
| |
» |
Voltage : AC 220V |
| |
» |
Dimensions : 98.5(W)x215.1(H)x68.3(D)mm |
|
|
|
|
 |
|
| Brand: |
M-TEK |
| Model |
MT-1025 |
| Product Name: |
4Inch Color TFT House hold Monitor |
| Product Warranty: |
365 Days |
|
Features |
| |
» |
Same as in other Audio door phones |
|
|
|
|
 |
|
| Brand: |
M-TEK |
| Model |
MT-25K + MT-10K |
| Product Name: |
Audio Door Phone with Outdoor Unit |
| Product Warranty: |
365 Days |
|
Features |
| DP-2K |
| |
» |
Product Function : Talk with Door Station / Door Release |
| |
» |
Material : Plastic |
| |
» |
Wiring : Door – 2 wires, Door Release – 2 wires |
| |
» |
Voltage : AC 220V |
| |
» |
Dimensions : 98.5(W) x 215.1(H) x 68.3(D)mm |
|
| DR-2K |
| |
» |
Function : Call residential station |
| |
» |
Material : Diecasting panel / Flush mount type |
| |
» |
Wiring DR – 2K / 2 – Wire, DR – 4K / 4 – Wire, DR – 2KS / 2 - Wire |
| |
» |
Voltage Power is supplied form Room Unit |
|
|
|
|
 |
|
| Brand: |
M-TEK |
| Model |
MVDP-10 + MVDP 11 |
| Product Name: |
Audio Video Door Phone |
| Product Warranty: |
365 Days |
|
Features |
| MVDP-10 |
| |
» |
4" TFT LCD B/W Indoor Monitor with Hand Set |
| |
» |
Bi-directional communication with outdoor panel |
| |
» |
Door unlocking |
| |
» |
Monitoring entrance |
| |
» |
Monitoring 2 pcs extra CCTV cameras(optional) |
| |
» |
8 alarm stations(optional) |
| |
» |
Color: white with grey |
|
| MVDP-11 |
| |
» |
Aluminium alloy suface |
| |
» |
B/W CCD camera |
| |
» |
Infrared night vision function |
| |
» |
Calling indoor monitor |
| |
» |
Capacity: connecting 1~6 pcs indoor monitors |
| |
» |
Power supplied by indoor monitor |
| |
» |
Color: black/silver |
|
Specifications |
| MVDP-10 |
| |
» |
Temperature: -20~+50℃ |
| |
» |
Humidity: <85% |
| |
» |
Harmonic distortion: ≤5% |
| |
» |
Dimension: 225*190*49(mm) |
| |
» |
Installation: Surface wall mount type |
|
| MVDP-11 |
| |
» |
Working Voltage: DC18V |
| |
» |
Rated power: 2.5W |
| |
» |
Operating Temperature: -20~+70℃ |
| |
» |
Standby power consumption: 0.3W |
| |
» |
Camera: 1/4"CCD |
| |
» |
Resolution: 420TVLine |
| |
» |
Talking mode: Bi-directional communication |
| |
» |
Minimum illumination: 0.05LuX |
| |
» |
Talking time: 45S |
| |
» |
Dimension: 92*127*32 |
| |
» |
Installation: Surface wall mount type |
|
|
|
|
 |
|
| Brand: |
M-TEK |
| Model |
MVDP-17PN + MDRC- 05DF |
| Product Name: |
Audio/ Video Door Phone |
| Product Warranty: |
365 Days |
|
Features |
| |
» |
Handset used two-way communication with the visitor |
| |
» |
Speaker Sounds a "Chime" tone when visitor pushes the camera "Call" button |
| |
» |
CRT Screen (4" B/W CRT) Displays image of a visitor or the camera viewing area |
| |
» |
Power LED Illuminates when power S/W is in "ON" Position |
| |
» |
Monitor Button Press to activate the outside camera and CRT screen to see camera viewing area |
| |
» |
Call Button Press to call the second monitor or interphone |
| |
» |
Door Release Button used to unlock an electronic door locking system |
| |
» |
Volume control S/W used to adjust the chime sound level |
| |
» |
Power "ON/OFF" S/W used to turn system power "ON" and "OFF" |
| |
» |
Brightness Control S/W used to adjust the brightness level of the CRT Screen |
| |
» |
AC Power Cord |
| |
» |
Terminal (see figure 5) used to connect wires from monitor to camera, interphone and image memory |
| |
» |
Front panel |
| |
» |
Infrared LED: Allows for the viewing of caller at any illumination |
| |
» |
CCD Camera Lens |
| |
» |
Lens Window |
| |
» |
Speaker: Provide high quality audio to a caller |
| |
» |
Call Button |
| |
» |
Microphone |
| |
» |
Screw cover |
| |
» |
Lever for angle adjustment |
| |
» |
Terminal |
| |
» |
Door Release cable |
|
Specifications |
| |
» |
Voltage Requirements: Voltage adaptability 100V-240V~,50/60Hz |
| |
» |
Power Consumption: Maximum 35VA; stand by 1VA |
| |
» |
Monitor Screen: B & W Flat 4" Flat Type |
| |
» |
Call Tone: 2 sound xylophone chime |
| |
» |
Audio Communication System: Duplex handset |
| |
» |
Maximum Wiring Distance: 50m/165feet (22AWG, 0.65mm 4wire) |
| |
» |
Estensions: Monitor or interphone |
| |
» |
Working Temperature: o°c to + 40°c |
| |
» |
Weight: 1.7kgs / 3.75lbs |
| |
» |
Dimension: 180(W) x 210(H) x 58(D)mm |
| |
» |
Pickup Device: B/W CCD, 1/3" |
| |
» |
Rated Voltage: 12V DC (From Monitor) |
| |
» |
Wiring (House/Door Release): 4Wire in polarity / 2Wire in Non-polarity |
| |
» |
Conversation Method: Synchronous |
| |
» |
Viewing Angle: H:75, V:55 |
| |
» |
Angle Adjustment: Upper: 10/Lower, Left, Right:7 |
| |
» |
TV System: EIA / CCIR |
| |
» |
Scanning Freq. (EIA/CCIR): H:15.734KHz, V:60Hz / H:15.625KHz, V:50HZ |
| |
» |
Min.Illumination: 0 Lux (300mm From Camera) |
| |
» |
Operating Temperature: -10c + 40c |
| |
» |
Dimension (mm): 125(W) x 183(H) x 50(D) |
| |
» |
Weight(g): 160 |
|
|
|
|
|
